Bug
-
Resolution: Unresolved
-
Critical
-
1.2.1
-
None
-
Quality / Stability / Reliability
-
False
-
-
1
-
None
-
None
-
None
-
Sprint 276
-
None
-
None
-
None
Install COO 1.2.0
Create UIplugin as below following doc https://github.com/rhobs/observability-operator/blob/main/docs/user-guides/observability-ui-plugins.md#monitoring and all the dashboards, deploy logging, tracing
Install ACM following doc https://docs.google.com/document/d/1BqWYq907iNHJYqDGsNROSglBvIhFQgUXrHIhMk7df9c/edit?tab=t.0
% oc -n open-cluster-management get csv NAME DISPLAY VERSION REPLACES PHASE advanced-cluster-management.v2.13.3 Advanced Cluster Management for Kubernetes 2.13.3 advanced-cluster-management.v2.13.2 Succeeded cluster-observability-operator.v1.2.1 Cluster Observability Operator 1.2.1 cluster-observability-operator.v1.2.0 Succeeded
apiVersion: observability.openshift.io/v1alpha1
kind: UIPlugin
metadata:
name: monitoring
spec:
type: Monitoring
monitoring:
acm:
enabled: true
alertmanager:
url: 'https://alertmanager.open-cluster-management-observability.svc:9095'
thanosQuerier:
url: 'https://rbac-query-proxy.open-cluster-management-observability.svc:8443'
perses:
enabled: true
incidents:
enabled: true
Perform upgrade to COO 1.2.1, upgrade successfully
% oc get csv NAME DISPLAY VERSION REPLACES PHASE cluster-logging.v6.2.3 Red Hat OpenShift Logging 6.2.3 cluster-logging.v6.2.2 Succeeded cluster-observability-operator.v1.2.1 Cluster Observability Operator 1.2.1 cluster-observability-operator.v1.2.0 Succeeded loki-operator.v6.2.3 Loki Operator 6.2.3 loki-operator.v6.2.2 Succeeded opentelemetry-operator.v0.127.0-1 Red Hat build of OpenTelemetry 0.127.0-1 opentelemetry-operator.v0.119.0-2 Succeeded tempo-operator.v0.16.0-1 Tempo Operator 0.16.0-1 tempo-operator.v0.15.4-1 Succeeded
After upgrade, Content of UIplugin monitoring disppeared
oc get uiplugin monitoring -oyaml
apiVersion: observability.openshift.io/v1alpha1
kind: UIPlugin
metadata:
annotations:
kubectl.kubernetes.io/last-applied-configuration: |
{"apiVersion":"observability.openshift.io/v1alpha1","kind":"UIPlugin","metadata":{"annotations":{"observability.openshift.io/api-support":"TechPreview"},"name":"monitoring"},"spec":{"type":"Monitoring"}}
observability.openshift.io/api-support: TechPreview
creationTimestamp: "2025-07-08T03:31:17Z"
finalizers:
- uiplugin.observability.openshift.io/finalizer
generation: 2
name: monitoring
resourceVersion: "192156"
uid: 30cdb585-413c-42d8-8b84-6759e25cc918
spec:
type: Monitoring
All the pods, such as perses, health-analyzer and troubleshooting are running
% oc get pod NAME READY STATUS RESTARTS AGE distributed-tracing-6cff77b7d-tcf7f 1/1 Running 0 22m health-analyzer-6f499ffcf5-pslzt 2/2 Running 0 22m korrel8r-564cdc6b99-6ln48 1/1 Running 0 22m logging-d87c468c7-nxrqh 1/1 Running 0 22m monitoring-5f7f69bb65-cnjh6 1/1 Running 0 22m obo-prometheus-operator-56bd84ffcc-kgxl4 1/1 Running 0 22m obo-prometheus-operator-admission-webhook-6b95f87dd4-qjr6p 1/1 Running 0 22m obo-prometheus-operator-admission-webhook-6b95f87dd4-xs7k5 1/1 Running 0 22m observability-operator-c6f65ccb9-jj7jj 1/1 Running 0 22m observability-ui-dashboards-55fd9c95cb-tzq4c 1/1 Running 0 22m perses-0 1/1 Running 0 3h46m perses-operator-69548c9d84-44xd8 1/1 Running 0 22m troubleshooting-panel-55774cb887-sdlck 1/1 Running 0 22m
After upgrade, see Error in logs of pod observability-operator 'observability-ui failed to reconcile plugin'
oc logs observability-operator-c6f65ccb9-jj7jj ...... 2025-07-08T07:06:42Z ERROR observability-ui failed to reconcile plugin {"plugin": {"name":"monitoring"}, "error": "monitoring configuration can not be empty for plugin type Monitoring"} github.com/rhobs/observability-operator/pkg/controllers/uiplugin.resourceManager.Reconcile /workspace/pkg/controllers/uiplugin/controller.go:263 sigs.k8s.io/controller-runtime/pkg/internal/controller.(*Controller[...]).Reconcile /cachi2/output/deps/gomod/pkg/mod/sigs.k8s.io/controller-runtime@v0.20.4/pkg/internal/controller/controller.go:119 sigs.k8s.io/controller-runtime/pkg/internal/controller.(*Controller[...]).reconcileHandler /cachi2/output/deps/gomod/pkg/mod/sigs.k8s.io/controller-runtime@v0.20.4/pkg/internal/controller/controller.go:334 sigs.k8s.io/controller-runtime/pkg/internal/controller.(*Controller[...]).processNextWorkItem /cachi2/output/deps/gomod/pkg/mod/sigs.k8s.io/controller-runtime@v0.20.4/pkg/internal/controller/controller.go:294 sigs.k8s.io/controller-runtime/pkg/internal/controller.(*Controller[...]).Start.func2.2 /cachi2/output/deps/gomod/pkg/mod/sigs.k8s.io/controller-runtime@v0.20.4/pkg/internal/controller/controller.go:255 2025-07-08T07:06:42Z ERROR Reconciler error {"controller": "uiplugin", "controllerGroup": "observability.openshift.io", "controllerKind": "UIPlugin", "UIPlugin": {"name":"monitoring"}, "namespace": "", "name": "monitoring", "reconcileID": "c16d7cb3-4403-42fc-8d93-b7b52aee17eb", "error": "monitoring configuration can not be empty for plugin type Monitoring"} sigs.k8s.io/controller-runtime/pkg/internal/controller.(*Controller[...]).reconcileHandler /cachi2/output/deps/gomod/pkg/mod/sigs.k8s.io/controller-runtime@v0.20.4/pkg/internal/controller/controller.go:347 sigs.k8s.io/controller-runtime/pkg/internal/controller.(*Controller[...]).processNextWorkItem /cachi2/output/deps/gomod/pkg/mod/sigs.k8s.io/controller-runtime@v0.20.4/pkg/internal/controller/controller.go:294 sigs.k8s.io/controller-runtime/pkg/internal/controller.(*Controller[...]).Start.func2.2 /cachi2/output/deps/gomod/pkg/mod/sigs.k8s.io/controller-runtime@v0.20.4/pkg/internal/controller/controller.go:255
