Several OCP rules are not multi-platform aware

XMLWordPrintable

    • Icon: Bug Bug
    • Resolution: Unresolved
    • Icon: Major Major
    • None
    • 4.18.z
    • Compliance Operator
    • None

      The file-groupowner-ovs-db-conf rule is written to be aware of the underlying system architecture:

      https://github.com/ComplianceAsCode/content/blob/master/applications/openshift/master/file_groupowner_ovs_conf_db/oval/shared.xml

      This is also apparent in the architecture-specific rules:

      platform: ocp4-node and not_s390x_arch

      As noted in the following file:

      https://github.com/ComplianceAsCode/content/blob/eae7cdd12b3b250c4c8e51ff0d5efddb766df7aa/applications/openshift/master/file_groupowner_ovs_conf_db_not_s390x/rule.yml

      However, while in the process of implementing ARM64 support for the Compliance Operator, I noticed that I couldn't get the rule to fail, even though the group owner for openvswitch configuration files is different than it is on x86.

      $ oc get ccr ocp4-cis-node-master-file-groupowner-ovs-conf-db -o yaml
      apiVersion: compliance.openshift.io/v1alpha1
      description: |-
        Verify Group Who Owns The Open vSwitch Configuration Database
        Check if the group owner of /etc/openvswitch/conf.db is hugetlbfs on architectures other than s390x or openvswitch on s390x.
      id: xccdf_org.ssgproject.content_rule_file_groupowner_ovs_conf_db
      instructions: |-
        To check the group ownership of /etc/openvswitch/conf.db,
        you'll need to log into a node in the cluster.
        As a user with administrator privileges, log into a node in the relevant pool:  $ oc debug node/$NODE_NAME  At the sh-4.4# prompt, run:  # chroot /host  Then,
        run the command:
        $ ls -lL /etc/openvswitch/conf.db
        If properly configured, the output should indicate the following group-owner:
        hugetlbfs on architectures other than s390x. On s390x, the
        group-owner should be openvswitch.
        Is it the case that <code>/etc/openvswitch/conf.db</code> does not have a group owner of
        code>hugetlbfs</code> on architectures other than s390x or <code>openvswitch</code>
        on s390x.?
      kind: ComplianceCheckResult
      metadata:
        annotations:
          compliance.openshift.io/last-scanned-timestamp: "2025-03-12T20:19:20Z"
          compliance.openshift.io/rule: file-groupowner-ovs-conf-db
        creationTimestamp: "2025-03-12T20:20:29Z"
        generation: 1
        labels:
          compliance.openshift.io/check-severity: medium
          compliance.openshift.io/check-status: PASS
          compliance.openshift.io/profile-guid: fea955f1-9f13-56fd-aacf-868b95b7283f
          compliance.openshift.io/scan-name: ocp4-cis-node-master
          compliance.openshift.io/suite: cis
        name: ocp4-cis-node-master-file-groupowner-ovs-conf-db
        namespace: openshift-compliance
        ownerReferences:
        - apiVersion: compliance.openshift.io/v1alpha1
          blockOwnerDeletion: true
          controller: true
          kind: ComplianceScan
          name: ocp4-cis-node-master
          uid: 212e2d8e-9d0f-4d12-b503-2c6b74f3abaf
        resourceVersion: "36363"
        uid: c731cfe5-16e7-4baa-800d-7f0485ad8ee4
      rationale: CNI (Container Network Interface) files consist of a specification and
        libraries for writing plugins to configure network interfaces in Linux containers,
        along with a number of supported plugins. Allowing writeable access to the files
        could allow an attacker to modify the networking configuration potentially adding
        a rogue network connection.
      severity: medium
      status: PASS

      When I ran the steps manually on the host, I can see the that owner is actually openvswitch:

      $ oc debug node/ip-10-0-112-168.us-east-2.compute.internal
      Starting pod/ip-10-0-112-168us-east-2computeinternal-debug-x65cr ...
      To use host binaries, run `chroot /host`
      Pod IP: 10.0.112.168
      If you don't see a command prompt, try pressing enter.
      sh-5.1# chroot /host
      sh-5.1# ls -la /etc/openvswitch/conf.db
      -rw-r-----. 1 openvswitch openvswitch 290853 Mar 12 20:41 /etc/openvswitch/conf.db

      I think the following rules are affected, based on how they're written:
