Uploaded image for project: 'Red Hat OpenShift Dev Spaces (formerly CodeReady Workspaces) '
  1. Red Hat OpenShift Dev Spaces (formerly CodeReady Workspaces)
  2. CRW-3563

Debugging the .NET sample with Dev Spaces default image (UDI) doesn't work (it works with a custom image)

    • True
    • Hide
      UDI image should be updated to ubi9.
      Depends on https://issues.redhat.com/browse/CRW-3185
      Show
      UDI image should be updated to ubi9. Depends on https://issues.redhat.com/browse/CRW-3185
    • False
    • Release Notes
    • Hide
      = Debugger does not work in the .NET sample

      Currently, the debugger in Microsoft Visual Studio Code - Open Source does not work in the .NET sample.

      .Workaround

      * Use a different image from the following sources:

      ** link:https://issues.redhat.com/secure/attachment/13065853/Dockerfile-1[Custom UBI-9 based Dockerfile]

      ** link:https://issues.redhat.com/secure/attachment/13065852/devfile-1.yaml[devfile.yaml]
      Show
      = Debugger does not work in the .NET sample Currently, the debugger in Microsoft Visual Studio Code - Open Source does not work in the .NET sample. .Workaround * Use a different image from the following sources: ** link: https://issues.redhat.com/secure/attachment/13065853/Dockerfile-1 [Custom UBI-9 based Dockerfile] ** link: https://issues.redhat.com/secure/attachment/13065852/devfile-1.yaml [devfile.yaml]
    • Known Issue
    • Done
    • Release Notes

      Description of problem:

      It's not possible to run any debug configuration in the .NET sample

      Steps to Reproduce

      1. Create a workspace from dotnet sample
      2. Select any debug configuration in the Debug view
      3. Try to run the debugger

      Actual results:

      The debugger should run

      Expected results:

      The debugger doesn't run

      Reproducibility (Always/Intermittent/Only Once):

      Always

      Additional info (Such as Logs, Screenshots, etc):

      After quick investigation no related logs in the browser console and Output view. Tested the same sample with the same VS Code extension on gitpod.io and the debugger worked.

      The debug functionality is provided by muhammad-sammy.csharp VS Code extension



      Screencast: screencast-devspaces.apps.ocp410.crw-qe.com-2022.11.25-12_04_58.mp4

            [CRW-3563] Debugging the .NET sample with Dev Spaces default image (UDI) doesn't work (it works with a custom image)

            Pinned comments

            Pinned by Charro Gruver

            Valerii Svydenko added a comment - - edited

            Debugger stop working with muhammad-sammy.csharp extension version v2.45.25 in UBI9, it worked in v2.39.29

            looks like new version of csharp extension requires GLIBCXX_3.4.30, I tried to run the debugger manually:

            /checode/remote/extensions/muhammad-sammy.csharp-2.45.25-universal/.debugger/netcoredbg/netcoredbg --interpreter=vscode


            and got

            /checode/remote/extensions/muhammad-sammy.csharp-2.45.25-universal/.debugger/netcoredbg/netcoredbg: /lib64/libstdc++.so.6: version `GLIBCXX_3.4.30' not found (required by /checode/remote/extensions/muhammad-sammy.csharp-2.45.25-universal/.debugger/netcoredbg/netcoredbg)

            [user@workspaceb4c81171ff624520-769f57cd7c-z9z4h dotnet-web-simple]$ strings /lib64/libstdc++.so.6 | grep GLIBCXX
            GLIBCXX_3.4
            GLIBCXX_3.4.1
            GLIBCXX_3.4.2
            GLIBCXX_3.4.3
            GLIBCXX_3.4.4
            GLIBCXX_3.4.5
            GLIBCXX_3.4.6
            GLIBCXX_3.4.7
            GLIBCXX_3.4.8
            GLIBCXX_3.4.9
            GLIBCXX_3.4.10
            GLIBCXX_3.4.11
            GLIBCXX_3.4.12
            GLIBCXX_3.4.13
            GLIBCXX_3.4.14
            GLIBCXX_3.4.15
            GLIBCXX_3.4.16
            GLIBCXX_3.4.17
            GLIBCXX_3.4.18
            GLIBCXX_3.4.19
            GLIBCXX_3.4.20
            GLIBCXX_3.4.21
            GLIBCXX_3.4.22
            GLIBCXX_3.4.23
            GLIBCXX_3.4.24
            GLIBCXX_3.4.25
            GLIBCXX_3.4.26
            GLIBCXX_3.4.27
            GLIBCXX_3.4.28
            GLIBCXX_3.4.29
            GLIBCXX_DEBUG_MESSAGE_LENGTH


            Valerii Svydenko added a comment - - edited Debugger stop working with muhammad-sammy.csharp extension version v2.45.25 in UBI9, it worked in v2.39.29 looks like new version of csharp extension requires GLIBCXX_3.4.30 , I tried to run the debugger manually: /checode/remote/extensions/muhammad-sammy.csharp-2.45.25-universal/.debugger/netcoredbg/netcoredbg --interpreter=vscode and got /checode/remote/extensions/muhammad-sammy.csharp-2.45.25-universal/.debugger/netcoredbg/netcoredbg: /lib64/libstdc++.so.6: version `GLIBCXX_3.4.30' not found (required by /checode/remote/extensions/muhammad-sammy.csharp-2.45.25-universal/.debugger/netcoredbg/netcoredbg) [user@workspaceb4c81171ff624520-769f57cd7c-z9z4h dotnet-web-simple]$ strings /lib64/libstdc++.so.6 | grep GLIBCXX GLIBCXX_3.4 GLIBCXX_3.4.1 GLIBCXX_3.4.2 GLIBCXX_3.4.3 GLIBCXX_3.4.4 GLIBCXX_3.4.5 GLIBCXX_3.4.6 GLIBCXX_3.4.7 GLIBCXX_3.4.8 GLIBCXX_3.4.9 GLIBCXX_3.4.10 GLIBCXX_3.4.11 GLIBCXX_3.4.12 GLIBCXX_3.4.13 GLIBCXX_3.4.14 GLIBCXX_3.4.15 GLIBCXX_3.4.16 GLIBCXX_3.4.17 GLIBCXX_3.4.18 GLIBCXX_3.4.19 GLIBCXX_3.4.20 GLIBCXX_3.4.21 GLIBCXX_3.4.22 GLIBCXX_3.4.23 GLIBCXX_3.4.24 GLIBCXX_3.4.25 GLIBCXX_3.4.26 GLIBCXX_3.4.27 GLIBCXX_3.4.28 GLIBCXX_3.4.29 GLIBCXX_DEBUG_MESSAGE_LENGTH

            A workaround is to use a workspace image built from Fedora 41

            Below is a working example -

            https://github.com/cgruver/dev-spaces-dotnet/tree/main/workspace-container-image

            Charro Gruver added a comment - A workaround is to use a workspace image built from Fedora 41 Below is a working example - https://github.com/cgruver/dev-spaces-dotnet/tree/main/workspace-container-image

            All comments

            A workaround is to use a workspace image built from Fedora 41

            Below is a working example -

            https://github.com/cgruver/dev-spaces-dotnet/tree/main/workspace-container-image

            Charro Gruver added a comment - A workaround is to use a workspace image built from Fedora 41 Below is a working example - https://github.com/cgruver/dev-spaces-dotnet/tree/main/workspace-container-image

            More findings related to air-gapped environments.

            Looking at this https://github.com/dotnet/vscode-csharp/blob/2f591c271ace0f4d9401ef1b0b4b41db0908fe65/package.json
            There are three different binaries that this extension tries to download once it gets installed in the VSCode:

            So, to get it working in an air-gapped environment, the following subdomains need to be opened for external access:

            .azureedge.net
            .blob.core.windows.net
            .visualstudio.microsoft.com

            Rafael Soares added a comment - More findings related to air-gapped environments. Looking at this https://github.com/dotnet/vscode-csharp/blob/2f591c271ace0f4d9401ef1b0b4b41db0908fe65/package.json There are three different binaries that this extension tries to download once it gets installed in the VSCode: Debugger -> https://vsdebugger.azureedge.net/coreclr-debug-2-0-5/coreclr-debug-linux-x64.zip OmniSharp -> https://roslynomnisharp.blob.core.windows.net/releases/1.39.10/omnisharp-linux-x64-net6.0-1.39.10.zip Razor -> https://download.visualstudio.microsoft.com/download/pr/0289a1d7-09a8-4aed-bf9a-e8942243fe9d/0[ …]rlanguageserver-linux-x64-7.0.0-preview.23516.2.zip So, to get it working in an air-gapped environment, the following subdomains need to be opened for external access: .azureedge.net .blob.core.windows.net .visualstudio.microsoft.com

            Another finding is that the C# extension used in this sample stack does not work on air-gapped environments, as it triggers an external dependency downloaded from microsoft.com [1] during its initialization at runtime.



            [1]https://github.com/dotnet/vscode-csharp/blob/2f591c271ace0f4d9401ef1b0b4b41db0908fe65/package.json#L774

            Rafael Soares added a comment - Another finding is that the C# extension used in this sample stack does not work on air-gapped environments, as it triggers an external dependency downloaded from microsoft.com [1] during its initialization at runtime.   [1] https://github.com/dotnet/vscode-csharp/blob/2f591c271ace0f4d9401ef1b0b4b41db0908fe65/package.json#L774

            I was able to get the debugger working using the latest release of the free-csharp-vscode (2.45.25) working on a custom tool image (based on quay.io/fedora/fedora-minimal:42). The custom tool image is available here quay.io/redhat_na_ssa/devspaces-dotnet-8:fedora42 and the devfile to test it is here https://github.com/rafaeltuelho/devspaces-dotnet-web-api-sample/blob/main/devfile.yaml

            Rafael Soares added a comment - I was able to get the debugger working using the latest release of the free-csharp-vscode (2.45.25) working on a custom tool image (based on quay.io/fedora/fedora-minimal:42). The custom tool image is available here quay.io/redhat_na_ssa/devspaces-dotnet-8:fedora42 and the devfile to test it is here https://github.com/rafaeltuelho/devspaces-dotnet-web-api-sample/blob/main/devfile.yaml

            Pinned by Charro Gruver

            Valerii Svydenko added a comment - - edited

            Debugger stop working with muhammad-sammy.csharp extension version v2.45.25 in UBI9, it worked in v2.39.29

            looks like new version of csharp extension requires GLIBCXX_3.4.30, I tried to run the debugger manually:

            /checode/remote/extensions/muhammad-sammy.csharp-2.45.25-universal/.debugger/netcoredbg/netcoredbg --interpreter=vscode


            and got

            /checode/remote/extensions/muhammad-sammy.csharp-2.45.25-universal/.debugger/netcoredbg/netcoredbg: /lib64/libstdc++.so.6: version `GLIBCXX_3.4.30' not found (required by /checode/remote/extensions/muhammad-sammy.csharp-2.45.25-universal/.debugger/netcoredbg/netcoredbg)

            [user@workspaceb4c81171ff624520-769f57cd7c-z9z4h dotnet-web-simple]$ strings /lib64/libstdc++.so.6 | grep GLIBCXX
            GLIBCXX_3.4
            GLIBCXX_3.4.1
            GLIBCXX_3.4.2
            GLIBCXX_3.4.3
            GLIBCXX_3.4.4
            GLIBCXX_3.4.5
            GLIBCXX_3.4.6
            GLIBCXX_3.4.7
            GLIBCXX_3.4.8
            GLIBCXX_3.4.9
            GLIBCXX_3.4.10
            GLIBCXX_3.4.11
            GLIBCXX_3.4.12
            GLIBCXX_3.4.13
            GLIBCXX_3.4.14
            GLIBCXX_3.4.15
            GLIBCXX_3.4.16
            GLIBCXX_3.4.17
            GLIBCXX_3.4.18
            GLIBCXX_3.4.19
            GLIBCXX_3.4.20
            GLIBCXX_3.4.21
            GLIBCXX_3.4.22
            GLIBCXX_3.4.23
            GLIBCXX_3.4.24
            GLIBCXX_3.4.25
            GLIBCXX_3.4.26
            GLIBCXX_3.4.27
            GLIBCXX_3.4.28
            GLIBCXX_3.4.29
            GLIBCXX_DEBUG_MESSAGE_LENGTH


            Valerii Svydenko added a comment - - edited Debugger stop working with muhammad-sammy.csharp extension version v2.45.25 in UBI9, it worked in v2.39.29 looks like new version of csharp extension requires GLIBCXX_3.4.30 , I tried to run the debugger manually: /checode/remote/extensions/muhammad-sammy.csharp-2.45.25-universal/.debugger/netcoredbg/netcoredbg --interpreter=vscode and got /checode/remote/extensions/muhammad-sammy.csharp-2.45.25-universal/.debugger/netcoredbg/netcoredbg: /lib64/libstdc++.so.6: version `GLIBCXX_3.4.30' not found (required by /checode/remote/extensions/muhammad-sammy.csharp-2.45.25-universal/.debugger/netcoredbg/netcoredbg) [user@workspaceb4c81171ff624520-769f57cd7c-z9z4h dotnet-web-simple]$ strings /lib64/libstdc++.so.6 | grep GLIBCXX GLIBCXX_3.4 GLIBCXX_3.4.1 GLIBCXX_3.4.2 GLIBCXX_3.4.3 GLIBCXX_3.4.4 GLIBCXX_3.4.5 GLIBCXX_3.4.6 GLIBCXX_3.4.7 GLIBCXX_3.4.8 GLIBCXX_3.4.9 GLIBCXX_3.4.10 GLIBCXX_3.4.11 GLIBCXX_3.4.12 GLIBCXX_3.4.13 GLIBCXX_3.4.14 GLIBCXX_3.4.15 GLIBCXX_3.4.16 GLIBCXX_3.4.17 GLIBCXX_3.4.18 GLIBCXX_3.4.19 GLIBCXX_3.4.20 GLIBCXX_3.4.21 GLIBCXX_3.4.22 GLIBCXX_3.4.23 GLIBCXX_3.4.24 GLIBCXX_3.4.25 GLIBCXX_3.4.26 GLIBCXX_3.4.27 GLIBCXX_3.4.28 GLIBCXX_3.4.29 GLIBCXX_DEBUG_MESSAGE_LENGTH

            Since in DS 3.9 che-code editor requires node 18.x, the old content of Dockerfile that installs node 16.x won't work
            We have to update workaround in the Release notes text, something like:

            • Use a different image from the following sources:
            • Starting from DS 3.9:

            jvrbkova@redhat.com could you take a look please

            Valerii Svydenko added a comment - Since in DS 3.9 che-code editor requires node 18.x, the old content of Dockerfile that installs node 16.x won't work We have to update workaround in the Release notes text, something like: Use a different image from the following sources: link: https://issues.redhat.com/secure/attachment/12960372/12960372_Dockerfile[Custom UBI-9 based Dockerfile] link: https://issues.redhat.com/secure/attachment/12960373/12960373_devfile.yaml[devfile.yaml ] Starting from DS 3.9: link: https://issues.redhat.com/secure/attachment/13065853/Dockerfile-1[Custom UBI-9 based Dockerfile] link: https://issues.redhat.com/secure/attachment/13065852/devfile-1.yaml[devfile.yaml ] jvrbkova@redhat.com could you take a look please

            rhn-support-mleonov : it's hard to read "Release Note Text:" with "-" at the middle:

            Currently, the debugger in Microsoft Visual Studio Code - Open Source does not work in the .NET sample.

            I would propose to distinguish editor name itself:

            Currently, the debugger in `Microsoft Visual Studio Code - Open Source` does not work in the .NET sample.

            Dmytro Nochevnov added a comment - rhn-support-mleonov : it's hard to read "Release Note Text:" with "-" at the middle: Currently, the debugger in Microsoft Visual Studio Code - Open Source does not work in the .NET sample. I would propose to distinguish editor name itself: Currently, the debugger in `Microsoft Visual Studio Code - Open Source` does not work in the .NET sample.

            Nick Boldt added a comment -

            For 3.6 I'd say we can use the upstream UDI (based on UBI 9) based image.

            For 3.8, we can look at having a UDI image in Dev Spaces that's based on UBI/RHEL 9, which we would deliver in parallel with the other UBI 8 based images; then over time we can migrate the rest of the 13 images to UBI 9 as well.

            Nick Boldt added a comment - For 3.6 I'd say we can use the upstream UDI (based on UBI 9) based image. For 3.8, we can look at having a UDI image in Dev Spaces that's based on UBI/RHEL 9, which we would deliver in parallel with the other UBI 8 based images; then over time we can migrate the rest of the 13 images to UBI 9 as well.

            Valerii Svydenko added a comment - - edited

            Custom UBI-9 based Dockerfile is:
            Dockerfile

            Devfile is:
            devfile.yaml

            It could be tested with this sample (the repository provides Devfile and Dockerfile as well): https://github.com/svor/dotnet-web-simple/tree/dotnet-custom-image

            Valerii Svydenko added a comment - - edited Custom UBI-9 based Dockerfile is: Dockerfile Devfile is: devfile.yaml It could be tested with this sample (the repository provides Devfile and Dockerfile as well): https://github.com/svor/dotnet-web-simple/tree/dotnet-custom-image

            For clarification: Debugging a .NET application is possible (now, with DS 3.5) using a custom image (no need to wait for Dev Spaces 3.6 or 3.7): vsvydenk please share Devfile and Dockerfile.

            I am changing the title of this issue to clarify that this issue is about the UDI image not perfectly crafted for the .NET sample and that, in general, debugging a .NET application with Dev Spaces is possible using a custom image.

            Mario Loriedo added a comment - For clarification: Debugging a .NET application is possible (now, with DS 3.5) using a custom image (no need to wait for Dev Spaces 3.6 or 3.7): vsvydenk please share Devfile and Dockerfile. I am changing the title of this issue to clarify that this issue is about the UDI image not perfectly crafted for the .NET sample and that, in general, debugging a .NET application with Dev Spaces is possible using a custom image.
