RFE: AAP enhancement for support using a Hashi vault client certificate for authentication

XMLWordPrintable

    • Icon: Feature Request Feature Request
    • Resolution: Unresolved
    • Icon: Normal Normal
    • None
    • 2.3
    • controller
    • False
    • False

      Description

      Customer is requesting workflow described in ticket as an RFE.

      Steps to Reproduce

      General process:
      Configuration needed:

      • Technical account to be used
      • URL for Hashivault
      • Owner name in certificate
      • Client certificate and key
      • Technical account for which the password is to be retrieved
        3 steps:
      • With certificate, name space, account name, get access temporary token
      • With temporary token, get path to secret for the technical account; may have several steps to get to the secret
      • With temporary token, get secret for the technical account

      Transcript (curl calls, secrets hidden):
      #============================================================================
      #./hashi-chk.pl: running hashicorp checks on AT1111
      #------------------------------------------------------------------------------

      #------------------------------------------------------------------------------

      1. getting tokens
        1. get token for runtime account FA11111
          /usr/bin/curl \
          --request POST \
          --cert ./cert/FA11111.pem \
          --key ./cert/FA11111.key \
          --data '{"name":"cert_fa11111"}' \
          -H "X-Vault-Namespace: AT1111" \
          https://vault.eu.eva.ubs.net/v1/auth/cert/login
          {"request_id":"f4daa1f6-6669-85e7-6f6a-b9845e4c5aa8","lease_id":"","renewable":false,"lease_duration":0,"data":null,"wrap_info":null,"warnings":null,"auth":{"client_token":"XXXXXXXXXXXXXXXXXXXXXXXXXXXXXX","accessor":"WmGrJLjR6AVRNzwYTF0k7V45.LRNKt","policies":["default","runtimeread"],"token_policies":["default","runtimeread"],"metadata": {"authority_key_id":"7f:b1:5e:e5:bf:3d:a1:59:43:ce:a6:4e:14:90:08:2a:1b:23:6b:b1","cert_name":"cert_fa11111","common_name":"FA11111","serial_number":"1003533744341219157921498326779946632709447242","subject_key_id":"a4:ee:63:62:e0:3d:52:bf:94:25:f5:7f:20:9e:d7:65:3a:0e:ee:79"}

          ,"lease_duration":1800,"renewable":true,"entity_id":"ac3083bf-f1be-b9a9-ded6-77221e779990","token_type":"service","orphan":true}}
          >> success: client_token for FA11111, runtime: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

      #------------------------------------------------------------------------------

      1. list secrets
        1. list secrets AT1111 using the token for runtime account FA11111 of XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
          /usr/bin/curl \
                  --request GET \
                  -H "X-Vault-Token: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXX" \
                  -H "X-Vault-Namespace: AT1111" \
                  https://vault.eu.eva.ubs.net/v1/secret/metadata/runtime?list=true
          !!!secrets: :18cd3b627c07ba6401309ba46009e522d88832b0eff01395877c8b7dc8650193:, @secrets: :18cd3b627c07ba6401309ba46009e522d88832b0eff01395877c8b7dc8650193: {"request_id":"62d8be1d-7ab3-09f8-c89e-b4cfcb7ed8f1","lease_id":"","renewable":false,"lease_duration":0,"data":\{"keys":["18cd3b627c07ba6401309ba46009e522d88832b0eff01395877c8b7dc8650193/"]}

          ,"wrap_info":null,"warnings":null,"auth":null}
          >> success: secret listing for path runtime: 18cd3b627c07ba6401309ba46009e522d88832b0eff01395877c8b7dc8650193

        1. list secrets AT1111 using the token for runtime account FA11111 of XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
          /usr/bin/curl \
                  --request GET \
                  -H "X-Vault-Token: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXX" \
                  -H "X-Vault-Namespace: AT1111" \
                  https://vault.eu.eva.ubs.net/v1/secret/metadata/runtime/18cd3b627c07ba6401309ba46009e522d88832b0eff01395877c8b7dc8650193?list=true
          !!!secrets: :SSO_SAMPLE,sso_other:, @secrets: :SSO_SAMPLE sso_other: {"request_id":"1bce8489-5674-8ed6-457b-63090712df4d","lease_id":"","renewable":false,"lease_duration":0,"data":\{"keys":["SSO_SAMPLE","sso_other"]}

          ,"wrap_info":null,"warnings":null,"auth":null}
          >> success: secret listing for path runtime/18cd3b627c07ba6401309ba46009e522d88832b0eff01395877c8b7dc8650193: SSO_SAMPLE sso_other

      #------------------------------------------------------------------------------

      1. get npta passwords
        1. get password for runtime account SSO_SAMPLE using the token for runtime account FA11111: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
          /usr/bin/curl \
          --request GET \
          -H "X-Vault-Token: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXX" \
          -H "X-Vault-Namespace: AT1111" \
          https://vault.eu.eva.ubs.net/v1/secret/data/runtime/18cd3b627c07ba6401309ba46009e522d88832b0eff01395877c8b7dc8650193/SSO_SAMPLE
          {"request_id":"74281b67-0005-bb23-51c5-fc5f84244bc0","lease_id":"","renewable":false,"lease_duration":0,"data":{"data": {"password":"XXXXXXXXXXXXXXXXXXXXXXXXXXXXXX"}

          ,"metadata":{"created_time":"2021-05-14T10:49:24.394741728Z","deletion_time":"","destroyed":false,"version":2}},"wrap_info":null,"warnings":null,"auth":null}
          >> success: got password: XXXXXXXXXXXXXXXXXXXX, account: SSO_SAMPLE, type: runtime, created: 2021-05-14T10:49:24.394741728Z, version: 2, retrieved by FA11111

      #==============================================================================

                  1. results summary #######
                    SWCI: AT1111, environment: prod, runtime vault account FA11111, deploy vault account FA15763
                    accounts checked: runtime: SSO_SAMPLE, runtime: sso_other, deploy: sso_otherd

      success: client_token for FA11111, runtime: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
      success: secret listing for path runtime: 18cd3b627c07ba6401309ba46009e522d88832b0eff01395877c8b7dc8650193
      success: secret listing for path runtime/18cd3b627c07ba6401309ba46009e522d88832b0eff01395877c8b7dc8650193: SSO_SAMPLE sso_other
      success: got password: XXXXXXXXXXXXXXXXXXXX, account: SSO_SAMPLE, type: runtime, created: 2021-05-14T10:49:24.394741728Z, version: 2, retrieved by FA11111

      #------------------------------------------------------------------------------
      #./hashi-chk.pl: completed hashicorp checks on AT1111
      #============================================================================

      Expected Behavior

       Request secrets from Hashicorp Vault using client certificate
